RTJ Flange

Standard Specification For rtj flange

  • Dimensions :ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
  • Size :1/2″ (15 NB) to 48″ (1200NB)
  • Class :150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc.
  • DIN :DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636,DIN 2637, DIN 2638, DIN 2673
  • BS : BS 4504 , BS 4504, BS 1560, BS 10
  • PN :PN6, PN10, PN16, PN25, PN40
  • Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
  •

Packaging of RTJ Flange

Packaging: RTJ Flange is sleeved into plastic bag individually, ten pieces wrapped with water-proof material, bundled with nylon rope. Clear labels are tagged on the outside of the package for easy identification of the quantity and product I.D. Great care is taken during operation and transportation.

Prevent any damage.
During transportation items are tagged, packed in plastic bags and closed in carton boxes or seaworthy wooden cases.

plywood case,pallet and according to customer’s requirment

Marking:RTJ Flange are marked with alloy name, outside diameter, wall thickness and heat number. Additional information like standard and alloy numbers can be added on request.

rtj flange
rtj flage

rtj flange- A Ring type joint flange(RTJ) is a machined metallic ring with a deep groove cut into its face. This groove rests a metal ring which gets compressed when the connecting bolts of the flange are tightened. This compression results in a leak-proof, close-fitting seal on the pipe or connection.

Material & Grades of RTJ Flange :
  • Stainless Steel RTJ Flange : ASTM A 182, A 240 F 304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H, 904L RTJ Flange
  • Duplex & Super Duplex Steel RTJ Flange : ASTM A182 / ASME SA182 F44, F 45, F51, F 53, F 55, F 60, F 61 RTJ Flange
  • Carbon Steel RTJ Flange : ASTM A105 / ASME SA105 ASTM / ASME A 350 , ASTM A181 LF2 / A516 Gr.70 A36, A694 F42, F46, F52, F60, F65, F706 RTJ Flange
  • Low Temperature Carbon Steel RTJ Flange: ASTM A350, LF2, LF3 RTJ Flange
  • Alloy Steel RTJ Flange : ASTM A182 / ASME SA182 & A387 F1, F5, F9, F11, F12, F22, F91 RTJ Flange
  • Copper Alloy Steel RTJ Flange : ASTM SB 61 , SB62 , SB151 , SB152 UNS No. C 70600 (Cu-Ni 90/10), C 71500 (Cu-Ni 70/30), UNS No. C 10100, 10200, 10300, 10800, 12000, 12200
  • Nickel Alloy RTJ Flange : ASTM SB564, SB160, SB472, SB162 Nickel 200 (UNS No. N02200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020) RTJ Flange

Application of RTJ Flange

  • ANSI B16.5 Class 150 RTJ Flange uses in Industrial Boilers Industry
  • ASTM A182 Stainless Steel RTJ Flange uses in Power Plants Industry
  • ASME B16.47 Series A and B RTJ Flange uses in Nuclear Plants Industry
  • Stainless Steel RTJ Flange uses in Oil & Gas Industry
  • Super Duplex Steel RTJ Flange uses in Refineries Industry
  • Industrial RTJ Flange uses in Ship Building Industry
  • Super Duplex Steel RTJ Flange Forged Flanges uses in Heat Exchanger Industry
  • Carbon Steel Industrial RTJ Flange uses in Condensers Industry
  • Alloy Steel Industrial RTJ Flange uses in Paper & Pulp Industry
  • Duplex Steel Industrial RTJ Flange uses in Marine Applications
  • Stainless Steel Industrial RTJ Flange uses in Nuclear Power Industry
  • Industrial RTJ Flange / Fittings System uses in Fossil Fuel Power Plants Industry

rtj flange dimensions of ASME B16.11

rtj flange

INDUSTRIES WE CATERS INDUSTRIAL FORGE FITTING

  • Ronak Overseas has many years of experiance of export and supply of ASME B16.11 Forged Fittings that is extensively used in the following industries:
  •  Refineries
  •  Gas Processing
  •  Off-Shore Oil Drilling Companies
  •  Petrochemicals
  •  Hydro-Carbon
  •  Fertilizers
  •  Paper & Pulp Companies
  •  Power Generation
  •  Specialty Chemicals
  •  Pharmaceuticals
  •  Drugs
  •  Steel
  •  Cement
  •  Water Pipe Line
  •  Pesticides
  •  General Piping
  •  Construction
  •  Engineering
  •  Nuclear
  •  Food Processing & Dairy
  •  boiler & heatexchangers
